Tyvek / DuPont™ Tychem® 9000

BR528T YL

DuPont™ Tychem® 9000

DuPont™ Tychem® 9000 Encapsulated Level B Suit. Expanded Back, Rear Entry. Standard Visor, 1 Layer: 20 mil PVC. Elastic Wrists. Attached Socks with Outer Boot Flaps. Double Storm Flap with Hook & Loop Closure. Two Exhaust Vents. Taped Seams. Yellow.




Hover over image to zoom
Name Description
Full Part Number BR528TYLxx0001yy (xx=size;yy=option code)  Help
Fabric/Materials Tychem® 9000
Design Encap. Level B, Exp Back, Rear Entry
Seam Taped
Color Yellow
Quantity/Box 1 per case
Sizes SM, MD, LG, XL, 2X, 3X, 4X
Option Codes 00

FEATURES & PRODUCT DETAILS

DuPont™ Tychem® 9000 offers wide-ranging protection backed by extensive fabric permeation barrier testing. Tychem® 9000 fabric provides at least 30 minutes of protection against more than 280 chemical challenges, including chemical warfare agents. Tychem® 9000 offers tear, puncture and abrasion resistant fabrics for lasting protection. Tychem® 9000 garments are designed for enhanced comfort and ease of movement. High visibility yellow.

  • Encapsulated design provides protection from liquid splash exposure for both the wearer and respiratory equipment
  • Also provides coverage from overhead liquid splash (does not provide vapor protection)
  • Taped seams provide strong chemical resistance against heavy liquid splashes. A sewn seam is covered with a strip of compatible chemical-resistant material through heat sealing.
  • Standard 20 mil PVC faceshield
  • Rear entry design keeps closure away from direct contact with frontal chemical exposure and provides ability to change air bottle on SCBA without removing the entire garment
  • Expanded back to accommodate self-contained air breathing apparatus (SCBA)
  • Storm flap covers zipper which can be secured by the wearer with rugged hook and loop material to prevent intrusion at zipper
  • Elastic opening for tighter fit at wrist
  • Integrated socks composed of garment material
  • Attached flaps are designed to cover boot tops to help reduce potential for liquid intrusion

AVAILABLE OPTIONS

FINISHED DIMENSIONS

ADDITIONAL EQUIPMENT NEEDED

FABRIC & CHEMICAL RESISTANCE DATA

Physical Properties

Data relating to mechanical performance of the fabrics used in DuPont chemical protective clothing, listed for the selected garment according to the test methods and relevant European standard, if applicable. Such properties, including abrasion and flex-cracking resistance, tensile strength and puncture resistance can help in the assessment of protective performance.

Property Test Method Typical Result
Thickness ASTM D1777 21.8 mils
Basis Weight ASTM D3776 8.1 oz/yd2
Burst Strength - Ball ASTM D751 129 lbf
Tear Resistance - Trap Tear (MD) ASTM D5597 42.5 lbf
Tear Resistance - Trap Tear (CD) ASTM D5597 35.7 lbf
Breaking Strength - Grab (MD) ASTM D5034 100.6 lbf
Breaking Strength - Grab (CD) ASTM D5034 104.7 lbf
Wearing Apparel Flammability 16 CFR 1610 Help Class 1

CHEMICAL RESISTANCE

SPECIAL WARNINGS
