DuPont™ ArmorWall™ Plus Fire-Rated Structural Insulated Sheathing

5-in-1 Composite Panel for DuPont™ ArmorWall™ System


DuPont™ ArmorWall™ Plus Fire-Rated Structural Insulated Sheathing

5-in-1 Composite Panel for DuPont™ ArmorWall™ System

<br><b>DuPont™ ArmorWall™ Plus Fire-Rated (FR) Structural Insulated Sheathing (SIS)</b> is an ICC listed (ESL-1302, ESL-1306, ESL-1442, ESL-1536, and ESL-1543), high strength, fire-resistant exterior wall sheathing product, with up to a two-hour fire rated assembly achievable. <b>ArmorWall™ Plus FR SIS</b> offers a factory-applied, high quality air and water-resistive barrier. Once seams and fasteners have been sealed the enclosure may be considered “dried-in”, allowing interior construction to commence regardless of final exterior finish status.<br><br>ArmorWall™ Plus FR SIS incorporates five traditional building enclosure elements into a single panel product: structural sheathing, fire-resistance, air barrier, water-resistive barrier, and a high-performance continuous insulation layer. The <b>five-in-one</b> system of <b>ArmorWall™ Plus FR SIS</b> can replace several traditional individual components, making it a cost-saving and labor-reducing option compared to traditional, individual components.







Features & Benefits





Air and Water-Resistive Barrier
  • Arrives complete to the jobsite with a factory-applied, high quality air and water-resistive barrier on the exterior sheathing.
  • Coating offers industry-leading exterior adhesion performance and compatibility with tapes, sealants, and other materials.
Cladding Attachment Support
  • Capable of handling many different claddings, attachments, and hangers, all of which attach directly into the component layers of the sheathing and no longer require attachment back to the stud frame or substrate assemblies.
Fusion Technology
  • High-performance, poured polyurethane insulation layer fused to our sheathing, which provides an easy way to comply with continuous insulation requirements in building codes.
  • Utilizes a 1/2" layer of Magnesium Oxide (MgO) sheathing on the exterior and interior face, providing top of the line fire-resistance, durability, and strength.
Install in Harsh Weather
  • Can be installed and cured in harsh weather conditions, with overall proven functionality of the panel in all outdoor environments.
  • Can be exposed to weather for up to 180 days.




Specifications





Standard Sizes

Thickness Sheathing Thickness Insulation Thickness Width Length R-Value NetWeight
2 in. 1/2 in. 1 1/2 in. 4 ft. 8 ft. 10 103 lbs
2 3/4 in. 1/2 in. 2 1/4 in. 4 ft. 8 ft. 15 110 lbs
3 3/4 in. 1/2 in. 3 1/4 in. 4 ft. 8 ft. 21 115 lbs




Testing

<b>DuPont™ ArmorWall™ Plus Fire-Rated Structural Insulated Sheathing,</b> when used as an approved DuPont commercial wall system, meets various Testing Standards. Applicable standards include:

TEST METHOD TEST TITLE PROPERTY RESULTS
FIRE
NFPA 2851 Standard Fire Test Method for Evaluation of Fire Propagation Characteristics of Exterior Wall Assemblies Containing Combustible Components Fire Resistance PASS
ASTM E84 Standard Test Method for Surface Burning Characteristics of Building Materials Flame Spread/Smoke Developed Index (MgO Board) 0 / 0
ASTM E84 Standard Test Method for Surface Burning Characteristics of Building Materials Flame Spread/Smoke Developed Index (insulation) 20 / 200
ASTM E119 Standard Test Methods for Fire Tests of Building Construction and Materials Hourly Rating 2 hrs assembly dependent
THERMAL
ASTM C518 Standard Test Method for Steady-State Thermal Transmission Properties by Means of the Heat Flow Meter Apparatus Thermal Resistance 6.5 per inch of insulation
STRENGTH
ASTM D1621 Standard Test Method for Compressive Properties of Rigid Cellular Plastics Foam Compression Range 30 psi
TAS 202-94 Criteria for Testing Impact & Non-Impact Resistant Building Envelope Components Using Uniform Static Air Pressure Deflection Properties PASS
TAS 203-94 Criteria for Testing Products Subject to Cyclic Wind Pressure Loading Cyclic Deflection Properties PASS
STRUCTURAL
ASTM E72 Standard Test Methods of Conducting Strength Tests of Panels for Building Construction Racking Resistance PASS
ASTM E330 Standard Test Method for Structural Performance of Exterior Windows, Doors, Skylights and Curtain Walls by Uniform Static Air Pressure Difference Deflection Properties Similar to TAS 202/203 - Data is in ESL-1306
AIR
ASTM E283 Standard Test Method for Determining Rate of Air Leakage Through Exterior Windows, Skylights, Curtain Walls, and Doors Under Specified Pressure Differences Across the Specimen Air Infiltration at 75 Pa 0.01 cfm/ft2 (0.1L/s/m2)
ASTM E283 Standard Test Method for Determining Rate of Air Leakage Through Exterior Windows, Skylights, Curtain Walls, and Doors Under Specified Pressure Differences Across the Specimen Air Infiltration at 300 Pa 0.04 cfm/ft2 (0.2L/s/m2)
ASTM E2357 Standard Test Method for Determining Air Leakage Rate of Air Barrier Assemblies Air Leakage Resistance PASS
WATER
ASTM E96 Standard Test Methods for Gravimetric Determination of Water Vapor Transmission Rate of Materials Procedure A Vapor Permeance (of 2" panel) 0.2 Perms (grains/hr in Hg ft2)
ASTM E3312 Standard Test Method for Water Penetration of Exterior Windows, Skylights, Doors, and Curtain Walls by Uniform Static Air Pressure Difference Water Penetration at 6.27 psf (300 Pa) PASS
GENERAL
ASTM D1970 Standard Specification for Self-Adhering Polymer Modified Bituminous Sheet Materials Used as Steep Roofing Underlayment for Ice Dam Protection Fastener Sealability3 PASS
ASTM C1338 Standard Test Method for Determining Fungi Resistance of Insulation Materials and Facings Mold and Mildew PASS
ASTM D17614 Standard Test Methods for Mechanical Fasteners in Wood and Wood-Based Materials Fastener Shear in Sheathing Only 519 lbs
ASTM D17614 Standard Test Methods for Mechanical Fasteners in Wood and Wood-Based Materials Fastener Pull Through 505.2 lbs
ASTM D17614 Standard Test Methods for Mechanical Fasteners in Wood and Wood-Based Materials Fastener Withdrawal Capacity 284 lbs

1ArmorWall™ Plus FR SIS passes NFPA 285 attached directly to the stud framing allowing most cladding installed to its exterior as inclusive to the NFPA 285 approved assembly

2Total test duration two continuous hours.

3ArmorWall™ Plus FR SIS is self-sealing around cladding attachment fasteners.

4Fastener data reflects attachment to the panel not attachment to structure.





Shear Properties

Fastener Type Min. Fastener Penetration into Framing Panel Applied Direct to Framing (Fastener Spacing at Panel Edges in Inches) Panel Applied Direct to Framing w/ 1/2" Gypsum on Opposite Face (Fastener Spacing at Panel Edges in Inches)
Shear (lbs/ft) w/ Framing of Douglas - Fir - Larch or Southern Pine with blocked perimeters
12" 6" 4" 6"
#14-13 1" 301 lbf (RNV) 437.5 lbf (RNV) 537.5 lbf (RNV) 570 lbf (RNV)
#14-13 1" 150 lbf (ASD) 218.75 lbf (ASD) 268.75 lbf (ASD) 285 lbf (ASD)
#14-13 1" 240 lbf (LFRD) 350 lbf (LRFD) 430 lbf (LRFD) 456 lbf (LRFD)

Deflection Properties

Property Test Method Stud Thickness Span Results
L/240 TAS 202-941 18 ga 86" +113/-95 psf (+5400/-4560 Pa)
L/240 TAS 202-941 20 ga 86" +60/-40 psf (+2880/-1920 Pa)
L/360 TAS 202-941 18 ga 86" +113/-75 psf (+5400/-3600 Pa)
L/360 TAS 202-941 20 ga 86" +60/-25 psf (+2880/-1200 Pa)
TAS 203-942 18 ga +113/-95 psf (+5400/-4560 Pa)
TAS 203-942 20 ga +60/-40 psf (+2880/-1920 Pa)

1Impact and Non-impact Resistance Building Envelope Components Using Uniform Static Air Pressure per Florida Building Code 6 Edition (2017) Section 1604.

2Criteria for Testing Products Subject to Cyclic Wind Pressure Loading per Florida Building Code 6 Edition (2017) Section 1604.











Code Compliance

<b>DuPont™ ArmorWall™ Plus Fire-Rated Structural Insulated Sheathing</b> complies with the following codes:

Code Description
US Product Listings & Verifications ESL-1302 - Hourly Rated Walls<br>ESL-1306 - Deflection Properties - ASTM E330<br>ESL-1442 - Exterior Wall Fire Properties - NFPA 285<br>ESL-1536 - Racking Resistance - ASTM E72<br>ESL-1543 - Cladding Fastener Spacing Tables













FAQ

What is the average weight of a DuPont™ ArmorWall™ Plus Fire-Rated (FR) Structural Insulated Sheathing (SIS) panel?

The weight for different thicknesses in of a standard ArmorWall™ Plus FR SIS panel is as follows:
2" Panel (R10): 103 lbs.
2 ¾" Panel (R15): 110 lbs.
3 ¾" Panel (R21): 115 lbs.
For more information on Panel Properties, please refer to the ArmorWall™ Product Information Sheets

How long can DuPont™ ArmorWall™ Systems be exposed to UV?

DuPont™ ArmorWall™ Plus and ArmorWall™ SP Plus Fire-Rated (FR) Structural Insulated Sheathing (SIS) can be exposed for up to 180 days to UV. After 180 days, the exposed panels need to be protected from further exposure. A DuPont Technical representative may, upon request, conduct a jobsite observation of the exposed product to consider an extension for panel UV exposure.

Is there a weight restriction for cladding that can be attached to ArmorWall™?

The ArmorWall™ System provides a complete structural attachment surface, allowing cladding to be attached anywhere along the face of the panels without fastening back to framing. There are not restrictions based on cladding weight and ESL 1543 provides cladding fastener structural performance for design by a qualified professional and prescriptive cladding attachment opportunities based on cladding weight. The report listing can be found here

What is the allowed limit for gaps in open joint rainscreen systems for DuPont™ ArmorWall™ Plus Fire-Rated (FR) Structural Insulated Sheathing (SIS) UV exposure?

The allowed limit for gaps in open joint rainscreen systems is up to 3/8" in width.

How do I cut ArmorWall™ Panels?

Tools commonly found on construction projects, such as circular saws and reciprocating saws can be used. Refer to the ArmorWall™ Installation Manual for cutting and installation instructions for the ArmorWall™ System. When cutting ArmorWall™ panels, DuPont recommends a dust mask, protective gloves, and eye protection. Additional respiratory protection is needed in areas with limited ventilation.

Can I get DuPont™ ArmorWall™ Fire-Rated (FR) Structural Insulated Sheathing (SIS) panels in custom sizes?

All ArmorWall™ FR SIS panels are 4′ x 8′.For more information, please refer to the ArmorWall™ Product Information Sheets.

What makes the DuPont™ ArmorWall™ Fire-Rated (FR) Structural Insulated Sheathing (SIS) panel so much stronger than other similar panels?

The strength of an ArmorWall™ FR SIS panel is due to our patented Fusion Technology and rigid component facing. These innovations provide our panels with higher structural strength compared to similar products in the marketplace, most of which are manufactured by laminating (similar to gluing) the structural and insulation layers together. Delamination may occurs when certain types of panels are exposed to moisture, heat or load.

Where can I get material safety data sheets (SDS) for ArmorWall™ Plus Fire-Rated Structural Insulated Sheathing, ArmorWall™ SP Plus Fire-Rated Structural Insulated Sheathing, or DuPont™ ArmorBoard™ Plus Fire-Rated Structural Sheathing?
These products are globally defined as articles, which do not require Safety Data Sheets according to chemical laws in the following:
• United States
• Canada
• European Union (EU) and other Europe/Middle East/African (EMEA) countries
• Asia Pacific countries (including Australia, China, Japan, South Korea, Thailand, etc.)

The products listed do not release or otherwise result in exposure to a hazardous chemical under the intended conditions of use and meet all other listed requirements of an article. Therefore, these products meet the global definitions of articles which do not require SDS creation or distribution.

Are DuPont™ ArmorWall™ Systems compliant with NFPA 285 standards?

Yes, the ArmorWall™ System complies with NFPA 285 standards testing with multiple claddings and assemblies. Please refer to ICC ESL-1442 for additional information. The report listing can be found here

What is the minimum fastener penetration into studs when attaching a DuPont™ ArmorWall™ Fire-Rated (FR) Structural Insulated Sheathing (SIS) panel to frame?

For steel studs, each screw must penetrate the frame with at minimum three threads showing beyond the metal surface. For wood studs and concrete, each screw must penetrate the substrate by 1" minimum of full fastener threads excluding drill tip and thread taper.

Is there an Engineering Judgement (EJ) for NFPA 285 available for DuPont™ ArmorWall™ Plus Fire-Rated (FR) Structural Insulated Sheathing (SIS)?

Yes. Please refer to ICC ESL-1442 for additional information. The report listing can be found here

Does DuPont™ ArmorWall™ Plus Fire-Rated (FR) Structural Insulated Sheathing (SIS) have fire-rated wall assemblies?

Yes. Please refer to ICC ESL-1302 for fire-rated ArmorWall™ Plus FR SIS assemblies. The report listing can be found here

How can DuPont™ ArmorWall™ Fire-Rated Structural Insulated Sheathing products help me meet my sustainability goals?

DuPont™ ArmorWall™ Fire-Rated Structural Insulated Sheathing products are:
• HFC Free
• Zero Ozone Depletion Potential
• Where sold by DuPont, compliant with state HFC regulations
• Certified by GreenCircle and eligible for LEED credits
In addition, the Global Warming Potential (GWP) of the blowing agent used in the polyurethane foam in ArmorWall™ is <10. Additional information can be found at DuPont™ ArmorWall™ Systems product webpage.
