DuPont™ FlexWrap™ EZ
Versatile Self-Adhered Flashing for Non-Flanged Objects
DuPont™ FlexWrap™ EZ
Versatile Self-Adhered Flashing for Non-Flanged Objects
<br><b>DuPont™ FlexWrap™ EZ</b> is a flexible, extendable self-adhered tape with a 100% butyl-based adhesive layer that helps create an air and water-tight seal around penetrations of all different shapes and sizes. <b>FlexWrap™ EZ</b> provides an option for home builders, trade contractors and remodelers to easily seal around non-flanged objects that penetrate the building envelope.
<br><br>
Suitable for both residential and commercial applications, <b>FlexWrap™ EZ</b> is ideal for flashing around many smaller wall protrusions like plumbing and HVAC components, vents, wires, exterior electrical outlets, exterior lights, exhaust fans, dryer vents, hose bibs, gas lines and more – a fast and easy solution to help improve energy efficiency and the durability of a wall system.
Features & Benefits
Specifications
Standard Sizes
| Unit | Width | Length | Units per Case | Cases per Pallet | Units per Pallet |
|---|---|---|---|---|---|
| Roll | 2 3/4 in. | 15 ft. | 16 | 24 | 384 |
Testing
<b>DuPont™ FlexWrap™ EZ</b> exhibits physical properties as indicated below when tested as represented. Review all instructions and (Material) Safety Data Sheet ((M)SDS) before use. Please contact DuPont at 1-833-338-7668 when additional guidance is required for writing specifications that include this product.
| TEST METHOD | TEST TITLE | PROPERTY | RESULTS |
|---|---|---|---|
| AIR | |||
| ASTM E1677 | Standard Specification for Air Barrier (AB) Material or Assemblies for Low-Rise Framed Building Walls | Assembly Air Leakage | < 0.04 cfm/ft2 (0.2 L/s • m2) |
| ASTM E2357 | Standard Test Method for Determining Air Leakage Rate of Air Barrier Assemblies | Assembly Air Leakage | < 0.04 cfm/ft2 (0.2 L/s • m2) |
| WATER | |||
| ASTM E331 | Standard Test Method for Water Penetration of Exterior Windows, Skylights, Doors, and Curtain Walls by Uniform Static Air Pressure Difference | Installed System Water Intrusion Testing. | NO leakage at 300 Pa (6.24 psf) |
| ASTM E331 | Standard Test Method for Water Penetration of Exterior Windows, Skylights, Doors, and Curtain Walls by Uniform Static Air Pressure Difference | Installed System Water Intrusion Testing (after thermal aging (0-120°F) | NO leakage at 300 Pa (6.24 psf) |
| ASTM E96 | Standard Test Methods for Gravimetric Determination of Water Vapor Transmission Rate of Materials | Water Vapor Permeability | < 1 perm (< 60 ng/Pa.sec.m2) |
| GENERAL | |||
| AAMA 711 | Specification for Self-Adhering Flashing Used for Installation of Exterior Wall Fenestration Products | Dupont Flashing Systems Products Meet the AAMA 711 Material Standard at the Highest Classification Levels | Class A (no primer) Level 3 Thermal Exposure (80°C/176°F for 7 days) |
Note:- *Tested in a wall assembly containing a window. Consult DuPont for primer recommendations
